Air Curtains: Screenzone Extra Wide 9kW-16kW

Screenzone Extra Wide Air Curtains 9kW, 12kW, 14kW or 16kW

Screenzone extra wide air curtains providing a welcoming curtain of warmth for extra tall and wide double doorways in shops, hotels, offices and other commercial premises.

  • 9kW, 12kW, 14kW or 16kW rating
  • Single or 3 phase on CA13 models
  • 3 phase only on CA15 models
  • Suspended, wall or trunking mounted
  • Wall mounting brackets supplied for optional use and ease of installation
  • Supplied with remote switch
  • 2 heat settings and 2 fan speeds
  • Multiple heaters can be controlled from one switch
  • Fan only setting for air circulation
  • Automatic safety cut-out for thermal overload protection
  • Finished in white

RXREC Receiver Unit - Wireless Control Conversion

Explore wireless control with our new RXREC receiver unit. With RXREC installed, a CRXSL controller* replaces the existing remote switch, expanding the heating control options to include temperature and time control.

∗ Requires a separately purchased CRXSL controller.

Dimensions & Specifications

  Maximum Mounting
Height (m)
Weight (kg) dBA Model No
9kW 3.4 20 52 CA1309S
12kW 3.4 20 52 CA1312S
9kW 3.4 22 55 CA1509S
12kW 3.4 22 55 CA1512S
14kW 3.4 22 55 CA1514S
16kW 3.4 22 55 CA1516S

Note:  The CA13 models replace the HE8333 & HE8350.

Dimensions:

Height (mm) Depth (mm) Width (mm)
276 199 1305 (CA13)
276 199 1530 (CA15)

Note: 300mm clearance from ceiling required.
